Silicon Wafers

SILICON WAFERS are the building blocks of modern technology, they provide the substrate onto which circuits are constructed. We offer Prime, Test, Monitor, SEMI standard, and customized silicon wafers in all diameters from 2″ to 300mm.  Our Wafers meet the SEMI standards, along with customized options.

• Silicon On Insulator (SOI) Wafers: Chips fabricated on SOI wafers achieve 30% faster speeds and 80% lower power demands compared to CMOS devices. The SOI structure consists of three layers: a top active device layer for transistor fabrication, a buried oxide (BOX) insulator layer, and a bottom handle wafer layer.
• Silicon Float Zone Wafers: is a crystal growth technique that produces highly pure silicon wafers with fewer impurities than traditional methods.
• Silicon Thermal Oxide Wafers: Has high quality silicon thermal oxide wafers in all diameters from 2″ to 300mm.
• Silicon Nitride Wafers: Has different option of film processing for your silicon needs, including LPCVD nitride.
• On Insulator (SOI): Has high quality silicon thermal oxide wafers in all diameters from 2″ to 300mm.
• Fused Silica Wafers: is the amorphous phase of quartz (SiO2).
• Borofloat 33 Glass Wafers: is used in a wide range of applications like micro-optics, sensors, microlithography, semiconductor engineering, lighting, medical technology.
